Code: MZKIT1

BiGDUG Mezzanine Floor Kit | 2500h x 5416w x 4921d mm | 22m2

BiGDUG Mezzanine Floor Kit
Size
Delivery time: 31-40 Working Days
Product description

A cost-effective alternative to extending or moving premises. Our Mezzanine Floor Kits are available in three sizes, offering an affordable and effective solution for creating additional space for your business.

Installing a mezzanine floor in a warehouse can offer several significant benefits:

  • Space Optimization: Mezzanines utilize vertical space, effectively doubling or even tripling the usable area within the same footprint
  • Cost-Effectiveness: Instead of relocating or expanding the warehouse, mezzanines provide a more affordable solution to increase space
  • Improved Workflow and Efficiency: By creating additional storage or workspace, mezzanines can streamline operations and improve overall workflow
  • Enhanced Safety: Properly designed mezzanines can improve safety by organizing storage and reducing clutter on the main floor

Would you like to know more about the types of mezzanine floors?

Please contact our experts in Business Solutions at businessservices@bigdug.co.uk or 0330 332 6312.

  • High quality storage platforms in three possible sizes : 22m², 29m² or 35m²
  • Includes staircase, handrail and hinged door gate for pallets
  • Ideal for warehouses and storage units to create additional storage space
  • The mezzanine floor can support 500 kg/m² if evenly distributed
  • Mezzanine kits are calculated, produced and installed according to British and European ‘Eurocode’ standards
  • Contact us for custom sizes

Other Considerations:

Fire Protection

A mezzanine floor will need to be fire rated under the following conditions:

  • If the floor exceeds 20m in any direction
  • If the floor exceeds 400m²
  • If the floor is greater than 50% of the existing area
  • If the floor has more than 3 people working on it at the same time

CLICK  HERE TO FIND OUT MORE ABOUT MEZZANINE FLOORS

BESPOKE SOLUTIONS

If this ready-made option is not quite what you need, we can design a Mezzanine Floor to suit your requirements with made to measure sizes and configurations.

Please click here to enquire about a bespoke solution  Mezzanine Floor Enquiry form

BUILDING REGULATIONS / Local Authority Approval

All structures of this type require approval under statutory regulations. This will cover the means of escape, fire protection, location of staircases and could also include emergency lighting and fire detection.  This can be done either by the local authority or an accredited surveyor.

Alternatively, as part of the project service BiGDUG can provide a quote to put through the application for approval on your behalf if you prefer. Please contact our experts in Business Solutions at businesssolutions@bigdug.co.uk or 0330 332 6312.

LARGE PROJECTS AND INSTALLATION

Do you need help with a large project or installation? BiGDUG can arrange experienced, qualified installers for the installation of your mezzanine floor. Contact 0330 332 6312 or businesssolutions@bigdug.co.uk for information.

‌
‌
‌
‌
‌
