Code: LOEML100FP
Electric Mini Lifter | Capacity 100kg | Lift Height 1700mm | Forks and platform
Capacity
Key Feature
Code: LOEML100FP
Electric Mini Lifter | Capacity 100kg | Lift Height 1700mm | Forks and platform
Capacity
Key Feature
Code: LOEML100FP
Product not available
Currently not availableProduct description
The Electric Mini Lifter is lightweight and compact and is easily manouverable, very versatile and easy to operate. The lifter is designed to remove back strain from all types of lifting work. It can be used to lift items from the floor to 1.7m with a battery powered powerpack. The lifter is a perfect solution for narrow aisles and confined spaces thanks to it's overall size.
- Non marking swivel castor wheels, 2 of which are fitted with foot brakes
- 100kg Capacity
Specifications
| Specifications | LOEML100 | LOEML150 | LOEML250 |
|---|---|---|---|
| Capacity (kg) | 100 | 100 | 100 |
| Load Centre (mm) | 235 | 235 | 200 |
| Lift Height (mm) | 130-1700 | 130-1500 | 130-1905 |
| Total Height (mm) | 1970 | 1780 | 2220 |
| Total Width (mm) | 600 | 600 | 600 |
| Total Depth (mm) | 850 | 825 | 840 |
| Platform Size (LxW mm) | 475 x 600 | 475 x 600 | 475 x 610 |
| Fork Length (mm) | 400 | 400 | 400 |
| Width Over Forks (mm) | 330 | 330 | 330 |
| Battery (V/Ah) | 24/12 | 24/12 | 24/20 |
| Steer/Load Wheels (mm) | Ø125 / Ø75 | Ø125 / Ø75 | Ø125 / Ø75 |
| Weight (kg) | 66 | 63 | 90 |
